Screen Image

104 = FRONT CRANE

105 = REAR CRANE

Explanation

The bending leg retract sensor is faulty.

Causes

• Sensor wiring fault or short circuit
• Loss of power to sensor
• Faulty sensor

Operator Actions

• Use override code to continue operation
• Request service

Service Tasks

• Check the operation of the sensor is by going to VIEW SENSOR VALUES, VIEW SPECIAL OPTIONS, FRONT or REAR ANKLE.
• The error message is displayed when the both the Leg Retracted Switches are in the CLOSED state or when both switches are in the OPEN state.
• If both switches are in the CLOSED state then it is most likely there is a wiring fault, a short circuit or a sensor failure.
• If both switches are in the OPEN state then it is most likely there is a damaged wire, a wiring fault, loss of power to the sensor, or a sensor failure.
