1

S3-25980

S3-25981

Crane Base SB330 LH

Crane Base SB330 RH

1

1

2

S3-25928

Arm Bottom SB330

1

3

S3-26034

Centre Twistlock Crane Base SB330

2

4

S3-26040

Handle Twistlock Crane Base SB330

2

5

S3-26044

Block Spring Offside Bash Plate SB330

1

6

S3-26048

Plate Bash Offside Crane Base SB330

1

7

S3-25963

Plate Bash Bottom Arm L/H SB330

1

8

BE-29011

Bearing Glacier 60 ID x 40 long

8

9

S3-25938

Arm Top SB330

1

10

HC-26089

Kit Cylinder Hyd Bottom Lift SB330

1

HC-31629

Cylinder Hyd Bottom Lift SB330 Type 2

1

1

HC-23366

Block Cartridge Double Port

1

1

HC-25754

Cartridge Overcentre Non Vent 200-30

2

1

BE-29011

Bearing Glacier 60 ID x 40 long

4

1

HF-40479

Plug 1/4" BSPP (replaces HF-VST11-4A3C)

2

1

11

HC-26059

Kit Cylinder Hyd Top Lift L/H SB300

1

HC-25807

Cylinder Hyd TopLift L/H SB300/330

1

1

HC-25753

Block Cartridge SinglePort

1

1

HC-25754

Cartridge Overcentre Non Vent 200-30

1

1

BE-29011

Bearing Glacier 60 ID x 40 long

4

1

HF-40479

Plug 1/4" BSPP (replaces HF-VST11-4A3C)

1

1

12

S3-21705

Stabiliser Housing SB300

1

13

HC-26057

Kit Cylinder Hyd Stab Tilt SB300/SB330

1

HC-25809

Cylinder Hyd Stabilizer Tilt SB300/330

1

1

HC-23366

Block Cartridge Double Port

1

1

HC-25143

Cartridge Pilot Check IH 4CK901

2

1

BE-29011

Bearing Glacier 60 ID x 40 long

4

1

HF-40479

Plug 1/4" BSPP (replaces HF-VST11-4A3C)

2

1

14

HC-26056

Kit Cylinder Hyd Stab Ext SB360/SB300

1

HC-25805

Cylinder Hyd Stab Extn SB360/300/330

1

1

HC-23366

Block Cartridge Double Port

1

1

HC-25143

Cartridge Pilot Check IH 4CK901

2

1

HF-40479

Plug 1/4" BSPP (replaces HF-VST11-4A3C)

2

1

15

S3-21657

Stabiliser Extension SB300

1

16

S1-18365

Support Lower Stabiliser Leg Cyl SB360

2

17

S3-21833

Foot SB300

1

18

PN-21819

Pin A & D SB300 Ø60

2

19

FA-28935

Circlip 60mm

11

20

PN-21821

Pin C E & F SB300 Ø60

3

21

PN-21822

Pin G SB300 Ø60

1

22

S3-21824

Plate Keeper Pin G SB300

2

23

PN-21812

Pin B & I SB300

2

24

PN-21826

Pin L SB300 Ø60

1

25

PN-21823

Pin H SB300 Ø60

1

26

PN-18322

Pin J SB360 SB300 Ø45

1

27

FA-28923

Circlip External M45

2

28

PN-21817

Pin K SB300 Ø45

1

29

S1-21933

Bracket Control Valve

1

30

-

Danfoss valve PVEM

1

HC-29503

Valve Danfoss PVG32 No Coils SB360 Ram R

1

1

HC-29504

Valve Danfoss PVG32 No Coils SB300 LHC

1

1

HC-27073

Coil Danfoss 12V PVEM 157B4116

5

1

HC-27074

Coil Danfoss 24V PVEM 157B4128

5

1

31

FA-27891

Pin Roll M10 X 55

2

32

S1-31067

S1-31066

Wear Pad Side Flange C/Base 10mm

Wear Pad Side Flange C/Base 35mm

4

1

33

S3-31068

Wear Pad Crane Base 10mm SB330

4

34

TP-22361

Ball Steel

2

35

TP-22382

Spring Twistlock Centre

2

36

FA-28750

Screw Grub M10 X 012

2

38

S1-22507

Shim 60 I.D. X 75 O.D. X 1mm SB300

1

39

S1-22508

Shim 60 I.D. X 75 O.D. X 2mm SB300

1

40

S1-22509

Shim 60 I.D. X 75 O.D. X 5mm SB300

1

41

HC-20674

Clamp Double 16mm Pipe

5

42

HC-18602

Clamp Single 16mm Pipe

13

43

FA-28604

Screw Set Hex Gr 8.8 M8X20 ZP

18

44

FA-28827

Washer Flat M8X19 ZP

28

45

HC-25811

Clamp Double 1/2 Hose Plastic Dipped

10

46

FA-29759

Screw Socket Cap Gr 12.9 M8X20 ZP

10

47

FA-28838

Washer Flat M12X28.5 ZP

8

48

FA-28647

Bolt Hex Gr 8.8 M12X80 ZP

4

49

FA-28772

Nut Nyloc M12 ZP

4

50

FA-28730

Screw Socket Flat Head Gr 12.9 M6X20 ZP

4

51

S3-26156

Shim Load Transfer Foot 3mm SB300/SB330

2

52

S3-26155

Shim Load Transfer Foot 2mm SB300/SB330

2

53

S3-26154

Shim Load Transfer Foot 1mm SB300/SB330

2

54

S3-22162

Block Load Transfer 20mm SB330

2

55

S3-22161

Block Load Transfer 12mm SB330

2

56

FA-28711

Screw Socket Cap Gr 12.9 M8X80 Blk

6

57

58

S6-25959

Spacer Washer SB360 A&H Pin 2mm

1

59

S6-25958

Spacer Washer SB360 A&H Pin 1mm

1

60

S6-20471

Spacer Washer SB360 A&H Pin 4mm

1

61

S3-31031

Spacer OS Bash Plate C/Base SB330

1

62

S3-31032

Washer Spring Block Offside Bash Plate

1

63

S1-31484

Retainer Long Wear Pad C/Base

1

HC-26058

Kit Cylinder Hyd Top Lift R/H SB300/SB330

1

HC-25808

Cylinder Hyd TopLift R/H SB300/330

1

1

HC-25753

Block Cartridge Single Port

1

1

HC-25754

Cartridge Overcentre Non Vent 200-30

1

1

BE-29011

Bearing Glacier 60 ID x 40 long

4

1

HF-40479

Plug 1/4" BSPP (replaces HF-VST11-4A3C)

1

1
