1

S3-25980

Crane Base L/H SB330

1

2

S3-33128

Arm Bottom SB250

1

3

S3-26034

Centre Twistlock Crane Base SB330

2

4

S3-26040

Handle Twistlock Crane Base SB330

2

5

S3-26044

Block Spring Offside Bash Plate SB330

1

6

S3-26048

Plate Bash Offside Crane Base SB330

1

7

S3-25963

Plate Bash Bottom Arm L/H SB330

1

8

BE-29011

Bearing Glacier 60 ID x 40 long

8

9

BE-29011

Arm Top SB250

1

10

HC-33138

Kit Cylinder Hyd Bottom Lift SB150/180/250

1

11

HC-33139

Kit Cylinder Hyd Top Lift L/H SB250

1

12

S3-21705

Stabiliser Housing SB300

1

13

HC-33180

Kit Cylinder Hyd Stab Tilt SB250

1

14

HC-26056

Kit Cylinder Hyd Stab Ext SB360/SB330

1

15

S3-21657

Stabiliser Extension SB300

1

16

S1-18365

Support Lower Stabiliser Leg Cyl SB360

2

17

S3-21833

Foot SB300

1

18

PN-21819

Pin A & D SB300 Ø60

2

19

FA-28935

Circlip 60mm

11

20

PN-33133

Pin C E & F SB300 Ø60

3

21

PN-33133

Pin G SB300 Ø60

1

22

S3-21824

Plate Keeper Pin G SB300

2

23

PN-21812

Pin B & I SB300

2

24

PN-21826

Pin L SB300 Ø60

1

25

PN-21823

Pin H SB300 Ø60

1

26

PN-18322

Pin J SB360 SB300 Ø45

1

27

FA-28923

Circlip External M45

2

28

PN-21817

Pin K SB300 Ø45

1

29

S1-21933

Bracket Control Valve

1

30

S3-31484

Retainer Wear Pad Crane Base SB330

2

31

HC-26090

Danfoss valve PVEM

1

32

FA-27891

Pin Roll M10 X 55

2

33

S1-31066

Wear Pad Side Flange C/Base 35mm

4

34

S3-31068

Wear Pad Crane Base 10mm SB330

4

35

TP-22361

Ball Steel

2

36

TP-22382

Spring Twistlock Centre

2

37

FA-28750

Screw Grub M10 X 012

2

38

S1-22507

Shim 60 I.D. X 75 O.D. X 1mm SB300

1

39

S1-22508

Shim 60 I.D. X 75 O.D. X 2mm SB300

1

40

S1-22509

Shim 60 I.D. X 75 O.D. X 5mm SB300

1

41

HC-20674

Clamp Double 16mm Pipe

5

42

HC-18602

Clamp Single 16mm Pipe

13

43

FA-28604

Screw Set Hex Gr 8.8 M8X20 ZP

18

44

FA-28827

Washer Flat M8X19 ZP

28

45

HC-25811

Clamp Double 1/2 Hose Plastic Dipped

10

46

FA-29759

Screw Socket Cap Gr 12.9 M8X20 ZP

10

47

FA-28838

Washer Flat M12X28.5 ZP

8

48

FA-28647

Bolt Hex Gr 8.8 M12X80 ZP

4

49

FA-28772

Nut Nyloc M12 ZP

4

50

FA-28730

Screw Socket Flat Head Gr 12.9 M6X20 ZP

4

51

S3-26156

Shim Load Transfer Foot 3mm SB300/SB330

2

52

S3-26155

Shim Load Transfer Foot 2mm SB300/SB330

2

53

S3-26154

Shim Load Transfer Foot 1mm SB300/SB330

2

54

S3-22162

Block Load Transfer 12mm Flange SB300

2

55

S3-22161

Block Load Transfer 20mm Flange SB300

2

56

FA-28711

Screw Socket Cap Gr 12.9 M8X80 Blk

6

57

S6-20471

Spacer Washer SB360 A&H Pin 4mm

1

58

S6-25959

Spacer Washer SB360 A&H Pin 2mm

1

59

S6-25958

Spacer Washer SB360 A&H Pin 1mm

1

60

S3-25981

Crane Base R/H SB330

1

61

S3-25967

Plate Bash Bottom Arm R/H SB330

1

62

HC-33140

Kit Cylinder Hyd Top Lift R/H SB250

1
