Crane Module Operation Control

All operator controls are on the radio remote control. This remote control has:

• Two joysticks that control all lift arm and stabiliser leg movements.
• A two position stay put switch to select stabiliser leg and lifting arm operation or an optional multi position switch for other hydraulically controlled functions
• A Red "Mushroom" type stop button for Emergency Stop.
• Multi units also have a Three position stay put switch to select position of front 20', 40' and rear 20' (not required on Truck Mount models)

Sidelifter control valves have manual levers. In the event of an electrical breakdown the operating cycle can be completed manually by using these levers.
