SL0020 Alternator Monitoring Circuit for Bosch Alternators

Models and Markets

Any model fitted with aftermarket Bosch Alternator.

Information

The SMARTlift Alternator monitoring circuit requires an additional relay if a Bosch Alternator is fitted. Refer to circuit diagram below for information.
