17 Aug 2004 PDF File |
Version 1 |
Electrics |
|
Following is the EHF base layout and pin output for part number EL-27677. Note that Steelbro have used different suppliers for these bases. Each supplier has a different input terminal position however ALL bases have the same output positions.
